Opticon OPI-1101 CMOS Streckkodsläsare Radio Frequency: 2.4 GHz 2D med stativ Svart

Opticon OPI-OPI-1101 trådlös CMOS 2D Streckkodsläsare

• Sofistikerad ergonomisk design med ett utmärkt pris-till-prestanda förhållande
• Höghastighets trådlös 2D CMOS-bildkamera skanner
• Skannar och avkodar snabbt en mängd olika 1D och 2D streckkoder
• Läser streckkoder från LCD skärmar och mobiltelefoner
• Anpassade konfigurationsmöjligheter inklusive multi-read
• Förbättrad träningstolerans
• Förbättrad skanning av böjda, breda och dåligt tryckta streckkoder
• Liten formfaktor: 186 x 67 x 91 mm (BxHxD) och 140 gram inklusive batteri
• Radio Frequency: 2.4 GHz IEEE 802.15.4 och OPA-1101-dongel

Produktens egenskaper

Visual: 1 LED / large LED (red/green/orange) Non-visual: Buzzer
Operating keys
Entry options: 1 scan key
Communication
IEEE.802.15.4 2.4 Ghz (100 m) USB: ComPort emulation / HID USB
Power
Rechargeable battery: Polymer 3.7V 1200mAh Charging method: by USB
power retrieving cable Charging time: Ca. 4 hours
2D Imager Optics
Light source: Green aiming LED, red illumination LEDs Scan method: CMOS area
sensor, 752 x 480 pixels, gray scale Scan rate: 60 fps Focal distance: 104 mm
Trigger mode: Manual, multiple read, auto-trigger, stand detection Image format:
Windows Bitmap, JPEG, TIFF Gradulation: 1024, 256, 16, 2 Image output
mode: 4 resolutions (full, 1/2, 1/3, 1/4), 2 ranges (horizontal, vertical) Reading
pitch angle: -50 to 0˚, 0 to +50˚ Reading skew angle: -50 to 0˚, 0 to +50˚
Reading tilt angle: 360˚ CUrvature: R>16 mm (12-digit 0.15 mm Codabar),
R>20 mm (13-digit UPC) Min. resolution Code39 at PCS 0.9: 0.127 mm / 5 mil,
min. resolution QR Code and Data Matrix at PCS 0.9: 0.169 mm / 7 mil Min. PCS
value: 0.45 Field of view: Horizontal 40.6˚, Vertical 26.4˚ Depth of field: at
Code 39, 65 - 105 mm / 2.56 - 4.13 in (0.127 mm / 5 mil), 45 - 185 mm / 1.77 - 7.28
in (0.254 mm / 10 mil), 50 - 250 mm / 1.97 - 9.84 in (0.508 mm / 20 mil) Depth of
field: at QR Code, 70 - 95 mm / 2.76 - 3.74 in (0.211 mm / 8.4 mil), 35 - 165 mm /
1.38 - 6.50 in (0.381 mm / 15 mil)
Supported Symbologies
Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39,
Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5,
Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-
Optic, UK/Plessey Postal code: Chinese Post, Intelligent Mail Barcode, Korean
Postal Authority code, POSTNET 2D code: Aztec Code, Aztec Runes, Chinese Sensible
code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi
Code (mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code
Durability
Temperature in operation: 0 to 40˚C / 32 to 104˚F Temperature in storage:
-20 to 60˚C / -4 to 140˚F Relative Humidity: 10 - 90% Ambient light immunity:
Fluorescent 10,000 lx max, Direct sun 100,000 lx max, Incandescent 10,000
lx max Drop test: 1.5 m / 5 ft drop onto concrete surface
Physical
Dimensions (w x h x d): 67 x 186 x 91 mm / 2.64 x 7.32 x 3.58 in Weight body:
Ca. 140 g / 4.94 oz Case: ABS, black
Regulatory & Safety
Product compliance: CE, FCC, RoHS
Sold separately
Stand
OPI-1101
>
