Partner 10,1" TFT LCD (LED) Kunddisplay
Partner DP-101, 10.1" LCD, inkl. fristående fot i metall (VESA fäste) Kantlös frontpanel, IP54 klassad, USB interface, ström via USB porten,VESA 75x75 Upplösning 1280x800
The 10.1“ DP-101A is a compact, stylish and modern POS monitor. Its light weight and aluminum alloy housing is
ideal for a variety of installation environments. It fits perfectly in many business areas such as retail, hospitality
and many more. The monitor can be used as a customer display, with or without touch, as operator display as
well as for digital signage purposes. Customer information or advertising become a more and more increasing
demand in many business cases. The DP-101A can be attached as a 2nd monitor on many of our POS terminals or
as a stand-alone version through the optional stand or long pole options. Here the monitor is adjustable in height
and can be fixed easily in required position by the individual operator. With the VESA mounting compability the
installation options of the DP-101A are endless.
SPECIAL FEATURES
10.1 inches LCD with LED backlight
1280 x 800 WXGA resolution
Elegant design with aluminum alloy housing
USB or VGA interfaces
Supports VESA mounting
OPTIONAL
USB or VGA interface
10-point PCAP Touch
Aluminum Zig Zag stand
Long Pole Stand
Max. Resolution 1280 x 800
Size 10.1"
Brightness 280 nits
Contrast 500:1
Display Colors 16.7M
Response Time 20 ms
LED Backlight Life 20.000 hours
Viewing Angle Right 75° Left 75° / Upper 75° Lower 75°
Technology LCD with LED backlight
Touch (optional) 10-point PCAP Touch (USB touch)
Interfaces
USB version
1 x USB dual input (for power, video and touch)
3 Buttons (Up & Down for brightness, Power Button)
3 Buttons (Up & Down
for brightness, Power
Button)
1 x RJ11 (for touch)
1 x VGA
1 x Power Jack
5 Buttons (Exit, Up, Down, OSD Menu, Power Button)
Dimensions without stand 253.9 mm (W) x 179.0 mm (H) x 38.3 mm (D)
Weight without stand 1.02 kg
Environment
Operating Temperature 0°C ~ 40°C
Storage Temperature -20°C ~ 55°C
Operating Humidity 10% ~ 80%
Storage Humidity 10% ~ 80%
Others
Colors black; silver
VESA Mounting 75 x 75
Material Aluminum Alloy housing
Certifications CE, FCC
Power Adapter External power adapter 12V 2A DC (Only for VGA version)
Cable USB version: 1 x 2-in-1 USB
Optionen
Stands Long Pole Stand; Aluminum Zig Zag stand
Touch 10-point PCAP touch (USB touch)
LED Backlight Life 50.000 hours
DP-101A
TECHNICAL DATA
